The Honda Odyssey FL350R was a significant upgrade in Honda's line of off-road recreational vehicles. Originally scheduled for release in spring 1984, it was delayed until early 1985. The FL350R brought enhancements in engine performance, stability, and braking systems, making it a noteworthy model in the history of off-road vehicles.
Engine Specifications
- Engine Type: Two-stroke, single-cylinder
- Displacement: Original: 342 cc (20.9 cu in)
- After Recall: 329 cc (20.1 cu in)
- Bore x Stroke: Original Bore: 80 mm (3.1 in)
- After Recall Bore: 78.5 mm (3.09 in)
- Stroke: 68 mm (2.7 in)
- Compression Ratio: 6.6:1
- Carburetor: 32 mm (1.26 in) Keihin
- Fuel Mixture: Premix 20:1 with a minimum of 89 octane (Modern recommendation: 32:1)
- Ignition: Solid-state capacitor discharge ignition (CDI)
- Starting System: Electric and recoil starter
Transmission
- Type: V-belt torque converter with F/N/R gearbox
- Gears: One speed forward, neutral, and reverse
- Clutch: Automatic
Dimensions and Weight
- Length: 85 in (2,200 mm)
- Width: 61 in (1,550 mm)
- Height: 54.7 in (1,390 mm) to top of roll cage
- Wheelbase: 61 in (1,550 mm)
- Ground Clearance: 8.3 in (210 mm)
- Dry Weight: 592 lb (269 kg)
Suspension
- Front Suspension: Dual-trailing arms with hydraulic shocksWheel Travel: 4.3 in (110 mm)
- Rear Suspension: Diagonal link-type with gas-charged shocksWheel Travel: 5.9 in (150 mm)
Brakes
- Front Brakes: Dual hydraulic drums
- Rear Brake: Single hydraulic disc
Wheels and Tires
- Front Wheels: 10 x 5.5 in (250 x 140 mm), 4/110 mm bolt patternTires: 21x7x10 RT101
- Rear Wheels: 10 x 8 in (250 x 200 mm), 4/130 mm bolt patternTires: 24x11x10 RT502
Fuel Capacity
- Total Capacity: 3.1 US gallons (12 liters)Reserve: 0.7 US gallons (2.6 liters)
Notable Upgrades from FL250
Stability Enhancements
- To improve stability, the track width was increased:
- Front Track Width: 42.5 in (1,080 mm)
- Rear Track Width: 47.2 in (1,200 mm)
Brake Upgrades
- Replaced mechanical disc brakes with:Front: Dual hydraulic drums
- Rear: Hydraulic disc
Legacy
The FL350R was eventually replaced by the Honda Pilot FL400R in 1989, continuing Honda's innovation in off-road vehicle design.
